High-Efficiency Infrared Drying Line for Furniture Board & Molded Pulp Products - Energy-Saving Thermal Solution
Detalhes do produto:
| Lugar de origem: | CHINA |
| Marca: | Osmanuv |
| Certificação: | ISO9001 |
| Número do modelo: | OSM-UV-1320T |
| Documento: | 5 Meters IR Drying Machine.pdf |
Condições de Pagamento e Envio:
| Quantidade de ordem mínima: | 1 conjunto |
|---|---|
| Preço: | negotiable |
| Detalhes da embalagem: | Caixa de madeira |
| Tempo de entrega: | 45 dias |
| Termos de pagamento: | T/T. |
| Habilidade da fonte: | Negociação |
|
Informação detalhada |
|||
| Velocidade da correia transportadora: | 10-30m/min | Fonte de luz: | Luz UV |
|---|---|---|---|
| Worktable: | Flutuante | Marca do inversor: | Schneider |
| Pistola de pulverização: | adote a arma de pulverizador automática do americano GRACO | Durabilidade do revestimento: | Alta durabilidade |
| Medios de revestimento: | Cabeças de jato de tinta DOD | Tipo de rolo: | Fio de aço |
Descrição de produto
High-Efficiency Infrared Drying Line for Furniture Board & Molded Pulp Products - Energy-Saving Thermal Solution
Keywords: infrared drying line, furniture board drying, molded pulp dryer, customizable drying system, industrial infrared oven
Composition of Production Line:
Pre-drying infrared module, main infrared drying tunnel, heat circulation system, temperature control cabinet, conveyor belt system, cooling section, PLC control panel
Product Description:
This infrared drying line is specifically designed for rapid and uniform drying of furniture boards (MDF, particleboard) and molded pulp products. It ensures moisture removal with minimal energy consumption and reduced footprint compared to conventional drying methods.
Technical Parameters:
| Parameter | Specification |
|---|---|
| Heating Technology | Medium-wave infrared emitters |
| Temperature Range | 50-400°C (customizable) |
| Belt Width | 600-2000mm (customizable) |
| Drying Speed | 0.5-5 m/min (adjustable) |
| Power Supply | 380V/50Hz/3Phase (configurable) |
| Control System | Siemens PLC + 10" HMI touchscreen |
| Heating Power | 30-200kW (customizable based on capacity) |
Application:
Drying of furniture boards, molded pulp packaging, egg trays, and industrial fiber products.
Customization:
Fully customizable infrared emitter layout, belt width, heating zones, and temperature profiles to match specific product requirements.
Feature:
-
40% energy saving compared to hot air drying
-
Uniform heating without surface overheating
-
Quick response and precise temperature control
-
Minimal maintenance requirements
Support and Services:
Installation supervision, operator training, 24/7 technical support, spare parts supply
Packing and Shipping:
Modular design for easy shipping, weather-proof packaging, FOB/CIF terms available
FAQ:
Q: Can the line handle different product thicknesses?
A: Yes, the temperature and speed are fully customizable for various thicknesses.
